SKU: 953.030UK | Brand: Adastra

SKU: 953.030UK | Brand: Adastra

Adastra MM240 Mixer Amplifier 2 x 120W

Order Before 4pm for Next Working Day Delivery*

£233.32  Excl VAT £279.99  Inc VAT

Qty

Product Wishlist & Compare Placeholder

  • Order before 4pm for next working day delivery
  • Please note working days are Monday - Friday
  • If ordered before 4pm on a Friday, delivery would be Monday

  • Order before 4pm for next working day delivery
  • Please note working days are Monday - Friday
  • If ordered before 4pm on a Friday, delivery would be Monday

modal placeholder

Purchase Order Modal Placeholder



Compact 1U mixer-amp featuring a built-in media player with DAB+ and Bluetooth receiver. 3 mono inputs connect via XLR microphone or line input (switchable). Each of these inputs has switchable +20V… more

DAB+/FM radio tuner
Bluetooth receiver with unique serial ID
USB audio player

Compact 1U mixer-amp featuring a built-in media player with DAB+ and Bluetooth receiver. 3 mono inputs connect via XLR microphone or line input (switchable). Each of these inputs has switchable +20V phantom power for use with condenser microphones or D.I. boxes and channel 1 has a variable priority function. Two stereo auxiliary line inputs are provided on RCA connectors with a stereo line output. Media player operating modes include 3.5mm Aux input, USB audio player, DAB+/FM radio tuner and Bluetooth receiver for playback from a smart phone or tablet. Main left and right speaker outputs are connected using standard Speakon leads. Connect 2 or 4 speakers for a complete music and voice installation or mobile PA system for functions, conferences and fitness classes.

  • DAB+/FM radio tuner
  • Bluetooth receiver with unique serial ID
  • USB audio player
  • Switchable +20V phantom power
  • Variable priority muting for channel 1
  • 24V emergency mute contacts
  • Output power rms @ 4 Ohms2 x 120W
  • Power supply100-240Vac, 50/60Hz (IEC)
  • FuseT3.15A
  • Output power : 4 Ohms2 x 120Wrms
  • Inputs : Mic/Line3 x XLR (bal/unbal)
  • Inputs : Aux2 x L+R RCA
  • Input : line3.5mm jack to media player
  • Audio sourceDAB+/FM tuner, USB player, Bluetooth receiver
  • Line outputL+R RCA
  • Speaker outputsL+R SPK connector
  • Emergency control24V contacts mute all except channel 1
  • Phantom power+20V (switchable channels 1-3)
  • Bluetooth version5.0
  • ControlsMedia, 3 x Mic/Line, 2 x Aux, Treble, Bass, Master level
  • Rear panel controlsPriority muting level, mic/line and phantom DIP switches
  • Input impedance2.2k Ohms (mic/line), 10k Ohms (aux)
  • Frequency response : mic20Hz - 18kHz
  • Frequency response : line14Hz - 20kHz
  • Frequency response : aux10Hz - 23kHz
  • Input sensitivity : mic/line-45dBV
  • Input sensitivity : aux/line-10dBV
  • Signal to noise ratio : mic55dB
  • Signal to noise ratio : aux/line60dB
  • Dimensions482 x 123 x 44mm
  • Weight1.96kg
